The Classeq D500 Duo compact commercial dishwashers are top specification, British made commerical dishwashers with all the extras you could want added as standard.
A remarkably easy to use and clean with Nationwide service and support in addition to simple installation into most commercial kitchens.

The Classeq D500Duo is the jewel of the Duo range. It's extra basket size makes it a must have for large sized venues, clubs and hotels. The WRAS compliant Type 'A' air gap fits all essential Water Board Regulations, while the double skinned, stainless steel finish allows for quiet operation and reduced heat loss. The three setting wash (3 minute standard, 5 minute heavy and 8 minute intensive clean) assuring a quick, quality clean.
The WRAS compliant Type 'A' air gap fits all essential Water Board Regulations, while the double skinned, stainless steel finish allows for quiet operation and reduced heat loss.

Onsite Warranty : 2 Year Parts & Labour

Basket Dimension : 500 x 500

External Dimension : W570 D605 H830 (860 max)

Wash Cycle Time : 180, 300 and 480 seconds

Power Requirements : 1x13A, 1x20A and 1x30A

Finish : Stainless Steel

Dimensions
Width	570mm
Depth	630mm
Height	835mm
Depth with door open	990mm
Internal Clearance	360mm
Max dran pump height	750mm
Technical
Max/Min water pressure	6 / 0.5 bar
Req water pressure flow	2 bar
Water Connection	3/4" BSP
Total electrical load	6.75kw
Wash tank temp	55 deg C
Rinse tank temp	85 deg C
Wash tank capacity	18 litre
Rinse tank capacity	.
Water consumption per cycle	2.5 litres approx
